Is the Safe Stop Function of the Industrial Remote Control Important?

Industrial remote controls are widely used in the control of mechanical operations. Through the use of the remote control, the operator can keep a distance from the working site of the machine and equipment, and the safety of the operator can be ensured. When the remote control is in use, if the operator finds an abnormal condition of the machine and equipment and must stop immediately, he can press the emergency stop button to complete the power-off shutdown to avoid damage to the machine and ensure the safety of personnel.

The emergency-off stopo system is very necessary. When the remote control system is working normally, the launching system sends 8-21 command data strings per second. The dual CUP microprocessor provides dual decoder redundancy and diversity technology to ensure the automatic shutdown of the remote control system in any abnormal working state, and avoid any error signal from generating an error command on the output communication interface of the receiving system.

There is an emergency stop button on the remote control of the crane. The operator sends an emergency stop command through the remote control to cut off the main power supply of the crane to stop the crane movement. In order to prevent the occurrence of unexpected situations, the active emergency stop must not have the automatic reset function. After the operator actively issues a stop command, the time to the crane's complete stop must be less than 0.5 seconds. Another form of emergency stop is passive. When the receiver detects an abnormal signal or the control system fails, the passive emergency stop remote control can automatically cut off the power to stop the crane mechanism. Passive emergency stop has no button setting and is built-in on the remote control. Most crane remote controls on the market have both emergency stop buttons and passive emergency stop functions.

There are emergency stop button, start button, up, down, left, right, front and back buttons on the remote control of bridge crane. The emergency stop button is very important. Its main function is to stop in dangerous situations. For example, when the bridge crane is sliding, the sliding hook can be controlled by pressing the emergency stop button.

Press the emergency stop button immediately after using the emergency stop button in the bridge crane. Because if the emergency stop button is not pressed, the bridge crane is energized. If you do not pay attention to touch other keys, it may cause a safety accident. If the vehicle is powered on for a long time, it will also affect the service life of the electrical components. For example, the warning light will flash for a long time, and the overload limiter will remain in working condition. Over time, the service life of these electrical devices will inevitably be shortened.

If the emergency stop button stays in the standby state for a long time, it will also shorten the service life and consume a lot of power. Therefore, when using bridge cranes, operators should also develop a good habit.

After the operating handle stops moving for 3 minutes, it will automatically power off the driving regardless of whether it will continue to be used. If you continue to use it, you need to reopen it. This avoids safety hazards caused by negligence or forgetting to press the emergency stop button.
